Model

YSTE200K

Sample & Reagent System

Sample Positions

37 sample positions

Reagent Position

28 reagent positions

Probe Washing

Automatic washing interior and exterior

Reagent Cooling

Refrigerated tray with independent switch

Reaction System

Temperature Control

37+0.1℃, real-time monitoring

Cuvettes

48 reusable cuvettes,optical length 6mm

Mixer Probe

Independent stirring

Washing

Automatic cuvettes washing

STAT function

YES

Optical System

Light Source

6V/10W halogen lamp

Spectrophotometry

Post-spectral spectrophotometry

Wavelength

340,405,450,510,546,578,630,700nm

Absorbance

0~3.0Abs

Calibration & QC

Calibration

Linear:K factor, 1-point ,2-point and multipoint linear Non-Linear:Spline,Polygon, Index, Ogarithm, Logit-4P, Logit-5P

Quality Control

Real-time QC, Westgard multi rule, Cumulative Sum Check,Twin Plot(2D)

Data Management

Software

Windows 7/8/10 , 32or 64bit

LIS System

Bi-direction,support HL7 protocol

Interface

LAN port access

Printer

External,multiple reporting mode available

Working Conditions

Power Supply

AC220V±10%,50/60Hz, 110V±10%,60Hz, 300W

Temperature

10~30℃

Water Consumption

Deionized water:<5L/H

Humidity

30-80%

Size & Weight

External Size (W*D*H)

625*425*460mm

Net Weight

36kg

Package Size (W*D*H)

721*531*855mm

Gross Weight

55kg
