Product Description
Description
1. Reasonable layout, simple and convenient operation.
2. Adopting a 7-inch touch screen display, the temperature display of each functional module is clear,
and both Chinese and English languages are optional.
3. Using PID constant temperature algorithm, precise temperature control with a control accuracy of
0.1℃.
4. Real time temperature curve display, making temperature control more intuitive.
5. Fast heating, uniform heating, superior performance, independent temperature control for each
branch, dual overheating protection for the temperature control system, safer and more reliable.
6. Intelligent wax melting mode, more efficient and intelligent.
7. Fully automatic program control, 7*24-hour automatic running time setting, more convenient;
Equipped with memory and automatic recovery functions, it automatically retains the preset
temperature after operation.
8. Large capacity wax melting cylinder, capable of accommodating 600 wax blocks for embedding at
once.
9. Manual and pedal dual waxing method.
10. The wax production time and flow rate can be adjusted.
11. Automatic shadowless lighting, adjustable brightness and lighting time.
12. Split design, the embedding machine and cryo console can be combined freely.
13. The left and right boxes, as well as the inner and outer boxes, are designed to be separated for
easy removal, wax replacement, and maintenance.
14. A spacious workbench with wax block repair device and flow channel design to prevent paraffin
overflow.
15. Equipped with a universal metal hose magnifying glass, suitable for handling extremely small
specimen tissues; Configure a semiconductor small cooling platform for instant cooling, facilitating
rapid positioning and embedding of specimens.
16. Lifetime free software upgrade.
Main Technical Data:
Main Console:
1. Wax cylinder capacity: 6L
2. Temperature control of wax cylinder, paraffin dispenser, working surface, left and right tank, and
tweezers block: 0-99℃
3. Environmental temperature: 0℃~45℃
4. Net weight: 25.5kg
5. Dimension: 650 * 647 * 465mm
6. Voltage: 220V 50Hz
7. Power: 800W
8. One time can handle 100 organizations
Cryo Console
1. Cooling temperature setting range: room temperature~-20 ℃
2. Power supply voltage: 220V, 50Hz
3. Power: 200W
4. Environmental temperature: Room temperature
5. Dimension: 632*410*446mm
6. Net weight: 20kg
Thermal Console
1. Power supply voltage: 220V, 50Hz
2. Power: 500W
3. Environmental temperature: 0~45 ℃
4. Relative humidity: ≤85%
5. Heating temperature setting range: 30~90 ℃
6. Working temperature: 30~70℃
7. Dimension: 410*660*450mm
8. Net weight: 11.5kg
Package Info:
Each instrument packed Wooden Case
Dimensions for main console: 760*750*700mm
Dimensions for cryo console: 720*490*640mm
Dimensions for thermal consol: 720*490*640 mm
Gross weight for main console: 50kg
Gross weight for cryo console: 45kg
