Product Description
Description
1. Laser printing without special printing supplies.
2. The printing speed is not less than 25 embedded boxes per minute (including QR code).
3. Can print all kinds of text, numbers, QR code, symbols.
4. The embedded box to be printed is placed horizontally and has a safety gap with the four sides of
the slot.
5. Single slot design.
6. Each tank is loaded with not less than 100 embedded boxes at one time
7. High printing clarity, to ensure that the printed two-dimensional code can be scanned reliably.
8. Long-term pre-filled packaging box strip, save the user manual loading trouble, to ensure the print quality.
9. Semi-transparent viewing window that can be opened and closed for easy observation of the
printing process.
10. The translucent viewing window is located directly in front of the marking machine.
11. The embedded box can be added at any time for special printing through the translucent
window.
12. In addition to the two-dimensional code, more than 8 fields of numeric and character information
can be printed.
13. It can be connected to HIS or LIS systems in hospitals.
14. The loading slot is located on the left side of the marking machine.
15. The exit of the printed buried box is located on the right side of the marking machine.
16. High printing clarity, to ensure that the printed two-dimensional code can be scanned reliably.
17. Long-term pre-filled packaging box strip, save the user manual loading trouble, to ensure the
print quality.
18. The embedded box upload is located on the left side of the machine, and the printed embedded
box output is located on the right side of the machine.
19. Printing software can realize batch printing and individual printing.
20. Print software can customize the print field name.
21. The number of editable print fields contained in the printing software is not less than 8.
22. The writing printed on the buried box should be scratch-resistant. Resistant to organic solvents.
23. The size of the printed QR code is not less than 6x6mm.
24. The printing software should contain a print editing window, a window to be printed and a printed
window.
25. The front width of the machine is less than 200mm.
26. The list to be printed has automatic data recovery function without loss of data.
27. You can export the printed information to a file for statistical analysis.
28. Using slide type embedded box conveying and printing structure, the embedded box slips freely
on the slide.
29. The embedding box is printed in the middle of the slide.
30. The printed embedded box slides freely to the bottom of the slide.
31. The printing position of the embedded box is controlled by the electric jacking rod in the middle
of the slide.
32.Recommended service life: 8 years
Laser marking machine configuration
1. 1 mainframe
2. 1 data cable
3. Buried strip seat 2
4. 2 embedding strips (50 embedding boxes per strip)
5. 1 power cord,
6. 1 user manual
Net Weight:19.8kg
Dimensions: 440*420*250mm
Package Info:
Each instrument packed in carton.
Dimensions: 545*345*515mm,
Gross Weight: 24.3kgkg
