36k-1ph-Hp Multi-split Outdoor unit - 2 to 5 outputs 38QUS Multi

Description

Max Lift 30 m
Refrigerant Pipe Size 3/8 – 5/8 in, 9.52 – 15.9 mm
Single Split / Multi Split Monosplit
R32 Cooling Capacity Min 3.90 kW
Family 38QUS
Annual Power Consumption 540/2870/2719 W
Refrigerant Amount 2.4 kg
Max Current 22.5 A
Refrigerant Charge 2.00 kg
Depth 410 mm
Sound Power Level 72 dB(A)
Sound Pressure Level 63.0 dB(A)
Cooling Capacity (Min/Rated/Max) 3.90-10.50-10.60 kW
Refrigerant R32
Heating Capacity (Min/Rated/Max) 2.90-11.00-13.50 kW
Power Consumption 5.0 kW
Temperature Range Heating -15°C~+24 °C
Temperature Range Cooling -15°C~+50 °C
Heating Capacity at -20°C 8.90 kW
SCOP 4.0/5.2
P Design Heating Capacity (Average) 8.2 kW
P Design Heating Capacity (Warmer) 10.10 kW
SEER 6.8
EER 2.63
COP 3.55
Recommended Fuse 25T
Air Flow 3800 m³/h
Additional Charge 24 g/m
Height 810 mm
Max Height Difference 30 m
Number Of Fans 1
Max Piping Length 65 m
Energy Label A++/A+/A+++
Width 946 mm
Standard Piping Length 5 m
Heating Capacity at -15°C 7.90 kW
Weight 66.9 kg
Min Piping Length 3 m
R32 Cooling Capacity Max 10.60 kW
Heating Capacity 11.00 kW
Power Supply 220-240/1/50 V/Ph/Hz
Cooling Capacity 10.5 kW
R32 Cooling Capacity Rated 10.50 kW
Heating Capacity at -7°C 9.30 kW
Indoor Units Connectable (Quantity) 1
R32 Power Input Rated Cooling 4.00 kW
